AVX Tantalum Capacitor 2.2μF 6.3V dc MnO2 Solid ±20% Tolerance TAC Series [TACK225M006QTA]; 166-7846
by AVX
0₫
Mã kho: 1667846
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Technology | MnO2 |
| Capacitance | 2.2 µF |
| Voltage | 6.3 V dc |
| Mounting Type | Surface Mount |
| Package/Case | 1005-07 |
| Equivalent Series Resistance | 15Ω |
| Tolerance | ±20% |
| Length | 1mm |
| Depth | 0.5mm |
| Height | 0.5mm |
| Dimensions | 1 x 0.5 x 0.5mm |
| Series | TAC |
| Electrolyte Type | Solid |
| Tolerance Plus | 0.2 |
| Maximum Operating Temperature | +125°C |
| Dissipation Factor | 0.08 |
| Leakage Current | 0.5 μA |
| Tolerance Minus | -0.2 |
| Terminal Type | Surface Mount |
| Minimum Operating Temperature | -55°C |
