AVX Tantalum Capacitor 33μF 10V dc MnO2 Solid ±20% Tolerance TAC Series [TACA336M010XTA]; 162-2901
by AVX
0₫
Mã kho: 1622901
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Technology | MnO2 |
| Capacitance | 33 µF |
| Voltage | 10 V dc |
| Mounting Type | Surface Mount |
| Package/Case | 3216-18 |
| Equivalent Series Resistance | 1Ω |
| Tolerance | ±20% |
| Length | 3.2mm |
| Depth | 1.6mm |
| Height | 1.6mm |
| Dimensions | 3.2 x 1.6 x 1.6mm |
| Series | TAC |
| Electrolyte Type | Solid |
| Tolerance Plus | 0.2 |
| Maximum Operating Temperature | +125°C |
| Minimum Operating Temperature | -55°C |
| Terminal Type | Surface Mount |
| Dissipation Factor | 0.12 |
| Leakage Current | 3.3 μA |
| Tolerance Minus | -0.2 |
