![Arcol HS50F 25R F 1859950](http://nguyenxuong.com/cdn/shop/products/Y1859950-01_444x263.jpg?v=1594421510)
Resistor Aluminium Housed 50W 1% 25R [HS50F 25R F]; 185-9950
by Arcol
0₫
Mã kho: 1859950
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Resistance | 25 Ω |
Power Rating | 50W |
Series | HS50F |
Package/Case | Aluminium Housed |
Tolerance | ±1% |
Technology | Aluminium |
Termination Style | Wire Lead |
Maximum Operating Temperature | +200°C |
Maximum Temperature Coefficient | +100ppm/°C |
Overall Width | 14.2mm |
Overall Height | 14.8mm |
Dimensions | 49.1 x 14.2 x 14.8mm |
Overall Length | 49.1mm |
