Resistor Aluminium Housed 100W 1% 12R [HS100F 12R F]; 185-9424
by Arcol
0₫
Mã kho: 1859424
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resistance | 12 Ω |
| Power Rating | 100W |
| Series | HS100F |
| Package/Case | Aluminium Housed |
| Tolerance | ±1% |
| Technology | Aluminium |
| Termination Style | Wire Lead |
| Maximum Operating Temperature | +200°C |
| Maximum Temperature Coefficient | +100ppm/°C |
| Overall Height | 24.1mm |
| Overall Length | 65.2mm |
| Dimensions | 65.2 x 27.3 x 24.1mm |
| Overall Width | 27.3mm |
