Alpha moulded Metal Foil Panel Mount Resistor, 50mΩ ±0.1% 12W [PSBXR0500B]; 335-466
by Alpha
0₫
Mã kho: 335466
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Resistance | 50 mΩ |
| Power Rating | 12W |
| Series | PSB |
| Package/Case | Planar |
| Tolerance | ±0.1% |
| Technology | Metal Foil |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +85°C |
| Minimum Temperature Coefficient | -5ppm/°C |
| Maximum Temperature Coefficient | +5ppm/°C |
| Overall Length | 100mm |
| Overall Height | 60mm |
| Overall Diameter | 20mm |
