Wurth Elektronik 618 Series, 26 Way Right Angle Through Hole PCB D-sub Connector Socket, 2.54 mm, 5.08 mm Pitch [618026330923]; 121-6783
0₫
Mã kho: 1216783
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 26 |
| Gender | Female |
| Body Orientation | Right Angle |
| Mounting Type | Through Hole |
| Pitch | 2.54 mm, 5.08mm |
| Termination Method | Solder |
| Current Rating | 3.0A |
| Housing Material | Steel |
| Voltage Rating | 125.0 V |
| Length | 39.2mm |
| Width | 12.5mm |
| Depth | 21.1mm |
| Dimensions | 39.2 x 12.5 x 21.1mm |
| Series | 618 |
| Minimum Operating Temperature | -40.0°C |
| Maximum Operating Temperature | +85°C |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
