Vishay VTVS5V0ASMF-M3-08, Uni-Directional TVS Diode, 400W, 2-Pin DO-219AB [VTVS5V0ASMF-M3-08]; 180-6533
by Vishay
0₫
Mã kho: 1806533
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Direction Type | Uni-Directional |
| Diode Configuration | Single |
| Maximum Clamping Voltage | 8.9V |
| Minimum Breakdown Voltage | 6.4V |
| Mounting Type | Surface Mount |
| Package Type | DO-219AB |
| Maximum Reverse Stand-off Voltage | 5V |
| Pin Count | 2 |
| Peak Pulse Power Dissipation | 400W |
| Maximum Peak Pulse Current | 42.95A |
| ESD Protection | Yes |
| Number of Elements per Chip | 1 |
| Minimum Operating Temperature | -55 °C |
| Maximum Operating Temperature | +175 °C |
| Automotive Standard | AEC-Q101 |
| Capacitance | 2.095nF |
| Test Current | 1mA |
| Maximum Reverse Leakage Current | 5µA |
| Dimensions | 2.9 x 1.9 x 0.98mm |
| Height | 0.98mm |
| Width | 1.9mm |
| Length | 2.9mm |
