STMicroelectronics HSP061-8M16, Octal TVS Diode Array, 16-Pin μQFN [HSP061-8M16]; 165-5909
0₫
Mã kho: 1655909
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Diode Configuration | Complex Array |
| Maximum Clamping Voltage | 14V |
| Minimum Breakdown Voltage | 6V |
| Mounting Type | Surface Mount |
| Package Type | μQFN |
| Maximum Reverse Stand-off Voltage | 3V |
| Pin Count | 16 |
| Maximum Peak Pulse Current | 3A |
| ESD Protection | Yes |
| Number of Elements per Chip | 8 |
| Minimum Operating Temperature | -40 °C |
| Maximum Operating Temperature | +150 °C |
| Dimensions | 3.4 x 1.6 x 0.53mm |
| Length | 3.4mm |
| Height | 0.53mm |
| Width | 1.6mm |
| Maximum Reverse Leakage Current | 100nA |
