ROHM RSBC6.8CMT2N, Bi-Directional TVS Diode, 100mW, 2-Pin SOD-923 [RSBC6.8CMT2N]; 183-5570
by ROHM
0₫
Mã kho: 1835570
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Direction Type | Bi-Directional |
| Diode Configuration | Single |
| Minimum Breakdown Voltage | 6.62V |
| Mounting Type | Surface Mount |
| Package Type | SOD-923 |
| Maximum Reverse Stand-off Voltage | 5V |
| Pin Count | 2 |
| Peak Pulse Power Dissipation | 100mW |
| ESD Protection | Yes |
| Number of Elements per Chip | 1 |
| Maximum Operating Temperature | 150 °C |
| Dimensions | 0.91 x 0.65 x 0.4mm |
| Height | 0.4mm |
| Width | 0.65mm |
| Test Current | 5mA |
| Length | 0.91mm |
| Maximum Reverse Leakage Current | 500nA |
| Capacitance | 1pF |
