COMCHIP TECHNOLOGY CPDU5V0U-HF, Uni-Directional ESD Protection Diode, 2-Pin SOD-523F (0603) [CPDU5V0U-HF]; 906-6905
0₫
Mã kho: 9066905
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Direction Type | Uni-Directional |
| Diode Configuration | Single |
| Maximum Clamping Voltage | 12.5V |
| Minimum Breakdown Voltage | 6V |
| Mounting Type | Surface Mount |
| Package Type | SOD-523F (0603) |
| Pin Count | 2 |
| Maximum Peak Pulse Current | 16A |
| ESD Protection | Yes |
| Number of Elements per Chip | 1 |
| Minimum Operating Temperature | -55 °C |
| Maximum Operating Temperature | +125 °C |
| Dimensions | 1.8 x 1 x 0.85mm |
| Test Current | 1mA |
| Width | 1mm |
| Height | 0.85mm |
| Length | 1.8mm |
| Maximum Reverse Leakage Current | 2µA |
| Capacitance | 120pF |
| ESD Voltage | 20kV |
