20kΩ Through Hole Trimmer Potentiometer 0.5W Side Adjust Copal Electronics CT-20 Series [CT-20EP 20k Ohm]; 474-8015
0₫
Mã kho: 4748015
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Resistance | 20 kΩ |
| Mounting Type | Through Hole |
| Number of Turns | 15 |
| Orientation | Side Adjust |
| Power Rating | 0.5W |
| Series | CT-20 |
| Termination Style | Pin |
| Tolerance | ±10% |
| Temperature Coefficient | ±100ppm/°C |
| Length | 19mm |
| Shaft Diameter | 2.5 mm |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | +120°C |
