| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Supply Voltage | 18 → 264 V ac, 18 → 300 V dc |
| Time Range | 0.01 → 99.9 h, 0.01 → 99.9 min, 0.1 → 99.9 s |
| Mode of Operation | Delay Cycle, Delay Pulse, Immediate Cycle, Interval, ON Delay Deenergise, ON Delay Energise |
| Mounting Type | Plug In |
| Number of Timer Functions | Multi Function |
| Number of Contacts | 1 |
| Time Increment | Hours, Minutes, Seconds |
| Power Supply | External |
| Contact Configuration | SP-NO/NC |
| Current Maximum | 0.416666666666667 |
| Terminal Type | 11-Pin Connector |
| Maximum Voltage | 30 V dc, 240 V ac |
| Minimum Operating Temperature | -20°C |
| Length | 48mm |
| Depth | 89.5mm |
| Maximum Operating Temperature | +60°C |
| Switch Configuration | SPDT |
| Contact Material | Silver Cadmium Oxide |
| Width | 48mm |
| Time Delay | 250 (Delayed Pulse) ms |
