Timer, On delayed [EF7616.24 AC50/60Hz 230V 0,15-1000s]; 181-2807
by Dold
0₫
Mã kho: 1812807
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Supply Voltage | 230 V ac |
| Time Range | 15 → 1000 s |
| Mode of Operation | Continuous |
| Mounting Type | Flush Mount |
| Number of Timer Functions | Single |
| Number of Contacts | 24 |
| Series | EF7616 |
| Time Increment | Seconds |
| Power Supply | External |
| Contact Configuration | NO/NC (Delayed), NO/NC (Instantaneous) |
| Current Maximum | 0.125 |
| Terminal Type | Screw |
| Maximum Voltage | 230 V ac |
| Depth | 72mm |
| Length | 72mm |
| Width | 128mm |
| Time Delay | <60 ms |
| Switch Configuration | SPDT |
| Maximum Operating Temperature | +55°C |
| Minimum Operating Temperature | -20°C |
