Dynex, DCR1010G14, Thyristor, 1400V 1010A, 300mA 3-Pin, Type G [DCR1010G14]; 760-9279
by Dynex
0₫
Mã kho: 7609279
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Rated Average On-State Current | 1010A |
| Thyristor Type | SCR |
| Package Type | Type G |
| Repetitive Peak Reverse Voltage | 1400V |
| Surge Current Rating | 15000A |
| Mounting Type | Stud |
| Maximum Gate Trigger Current | 300mA |
| Maximum Gate Trigger Voltage | 3V |
| Maximum Holding Current | 200mA |
| Pin Count | 3 |
| Height | 26.5mm |
| Dimensions | 58 (Dia.) x 26.5mm |
| Repetitive Peak Off-State Current | 60mA |
| Maximum Operating Temperature | +125 °C |
| Peak On-State Voltage | 1.35V |
| Repetitive Peak Forward Blocking Voltage | 1400V |
