Carling Technologies 200A 2 Pole Thermal Magnetic Circuit Breaker, 150 V dc, 240 V ac C [C22-P0-D4-820-31E-MT]; 881-4939
0₫
Mã kho: 8814939
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Current Rating | 200A |
Number of Poles | 2 |
Series | C |
Breaking Capacity at Maximum Voltage Rating | 5000 A @ 125/250 V dc, 10000 A @ 277 V ac |
Overall Length | 38.5mm |
Mounting Style | Panel Mount |
Application | General Purpose |
Overall Depth | 65.5mm |
Overall Dimensions | 38.48 x 63.5 x 65.54mm |
Reset Actuator Type | Rocker |
Circuit Breaker Type | MCCB |
Rated DC Voltage | 150V |
Special Features | The UL489 C-Series Employs A Unique Arc Chute Design Which Allows For Higher Interrupting Capacities Of Up to 10,000 Amps. New Thermoset Glass Filled Polyester Half Shell Construction Provides For Increased Mechanical and Electrical Strength |
Tripping Mechanism | Hydraulic-Magnetic |
Terminal Contact Type | Stud |
Break Time | Medium |
