Analog Devices ADT7301ARTZ-500RL7, Temperature Monitor -40 → +150 °C ±0.5°C SPI, 6-Pin SOT-23 [ADT7301ARTZ-500RL7]; 111-2272
0₫
Mã kho: 1112272
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Sensor Function | Temperature |
Output Type | Digital |
Interface Type | SPI |
Accuracy | ±0.5°C |
Mounting Type | Surface Mount |
Pin Count | 6 |
Minimum Operating Temperature | -40 °C |
Operating Temperature Range | -40 → +150 °C |
Maximum Operating Temperature | +150 °C |
Minimum Operating Supply Voltage | 2.7 V |
Maximum Operating Supply Voltage | 5.25 V |
Package Type | SOT-23 |
Length | 2.9mm |
Height | 1.15mm |
Width | 1.6mm |
Dimensions | 2.9 x 1.6 x 1.15mm |
Resolution | 13 bit |
