Vishay Tantalum Capacitor 3.3μF 50V dc MnO2 Solid ±10% Tolerance 293D Series [293D335X9050C2TE3]; 684-4070
by Vishay
0₫
Mã kho: 6844070
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Technology | MnO2 |
| Capacitance | 3.3 µF |
| Voltage | 50 V dc |
| Mounting Type | Surface Mount |
| Package/Case | 6032-28 |
| Equivalent Series Resistance | 2.5Ω |
| Tolerance | ±10% |
| Length | 6mm |
| Depth | 3.2mm |
| Height | 2.5mm |
| Dimensions | 6 x 3.2 x 2.5mm |
| Series | 293D |
| Electrolyte Type | Solid |
| Leakage Current | 1.7 μA |
| Tolerance Minus | -0.1 |
| Terminal Type | Surface Mount |
| Minimum Operating Temperature | -55°C |
| Tolerance Plus | 0.1 |
| Maximum Operating Temperature | +125°C |
| Dissipation Factor | 0.06 |
