Vishay Tantalum Capacitor 10μF 35V dc MnO2 Solid ±10% Tolerance 293D Series [293D106X9035C2TE3]; 684-3901
by Vishay
0₫
Mã kho: 6843901
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Technology | MnO2 |
Capacitance | 10 µF |
Voltage | 35 V dc |
Mounting Type | Surface Mount |
Package/Case | 6032-28 |
Equivalent Series Resistance | 1.6Ω |
Tolerance | ±10% |
Length | 6mm |
Depth | 3.2mm |
Height | 2.5mm |
Dimensions | 6 x 3.2 x 2.5mm |
Series | 293D |
Electrolyte Type | Solid |
Maximum Operating Temperature | +125°C |
Leakage Current | 3.5 μA |
Dissipation Factor | 0.06 |
Tolerance Minus | -0.1 |
Terminal Type | Surface Mount |
Minimum Operating Temperature | -55°C |
Tolerance Plus | 0.1 |
