KEMET Tantalum Capacitor 15μF 25V dc Polymer Solid ±20% Tolerance T521 Series [T521V156M025ATE040]; 121-3320
by KEMET
0₫
Mã kho: 1213320
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Technology | Polymer |
Capacitance | 15 µF |
Voltage | 25 V dc |
Mounting Type | Surface Mount |
Package/Case | 7343 |
Equivalent Series Resistance | 40mΩ |
Lead Pitch | 3.8mm |
Tolerance | ±20% |
Length | 7.3mm |
Depth | 4.3mm |
Height | 1.9mm |
Dimensions | 7.3 x 4.3 x 1.9mm |
Series | T521 |
Electrolyte Type | Solid |
Maximum Operating Temperature | +105°C |
Tolerance Plus | 0.2 |
Dielectric Material Family | Tantalum |
Minimum Operating Temperature | -55°C |
Tolerance Minus | -0.2 |
Polarised | Polar |
Leakage Current | 37.5 μA |
Dissipation Factor | 0.1 |
