T521 Cap Tantalum Polymer 22uF 20% 35VDC [T521D226M035ATE040]; 187-7269
by KEMET
0₫
Mã kho: 1877269
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Technology | Polymer |
Capacitance | 22 µF |
Voltage | 35 V dc |
Mounting Type | Surface Mount |
Package/Case | 7343-31 |
Equivalent Series Resistance | 40mΩ |
Tolerance | ±20% |
Length | 7.3mm |
Depth | 4.3mm |
Height | 2.8mm |
Dimensions | 7.3 x 4.3 x 2.8mm |
Series | T521 |
Electrolyte Type | Solid |
Leakage Current | 77 μA |
Minimum Operating Temperature | -55°C |
Dissipation Factor | 0.1 |
Tolerance Minus | -0.2 |
Tolerance Plus | 0.2 |
Polarised | Polar |
Maximum Operating Temperature | +125°C |
Dielectric Material Family | Tantalum |
