T520 Cap Tantalum Polymer 150uF 20% 10VD [T520V157M010ATE025]; 187-7047
by KEMET
0₫
Mã kho: 1877047
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Technology | Polymer |
Capacitance | 150 µF |
Voltage | 10 V dc |
Mounting Type | Surface Mount |
Package/Case | 7343-19 |
Equivalent Series Resistance | 25mΩ |
Tolerance | ±20% |
Length | 7.3mm |
Depth | 4.3mm |
Height | 1.8mm |
Dimensions | 7.3 x 4.3 x 1.8mm |
Series | T520 |
Electrolyte Type | Solid |
Tolerance Plus | 0.2 |
Dielectric Material Family | Tantalum |
Minimum Operating Temperature | -55°C |
Dissipation Factor | 0.1 |
Maximum Operating Temperature | +105°C |
Tolerance Minus | -0.2 |
Polarised | Polar |
Leakage Current | 150 μA |
