KEMET Tantalum Capacitor 100μF 10V dc Polymer Solid ±20% Tolerance T520 Series [T520V107M010ATE025]; 147-588
by KEMET
0₫
Mã kho: 147588
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Technology | Polymer |
| Capacitance | 100 µF |
| Voltage | 10 V dc |
| Mounting Type | Surface Mount |
| Package/Case | 7343-20 |
| Equivalent Series Resistance | 25mΩ |
| Tolerance | ±20% |
| Length | 7.3mm |
| Depth | 4.3mm |
| Height | 1.9mm |
| Dimensions | 7.3 x 4.3 x 1.9mm |
| Series | T520 |
| Electrolyte Type | Solid |
| Maximum Operating Temperature | +105°C |
| Leakage Current | 100 μA |
| Minimum Operating Temperature | -55°C |
| Tolerance Plus | 0.2 |
| Dielectric Material Family | Tantalum |
| Dissipation Factor | 0.1 |
| Tolerance Minus | -0.2 |
