KEMET Tantalum Capacitor 22μF 6.3V dc Electrolytic Solid ±20% Tolerance T520 Series [T520A226M006ATE090]; 173-7005
by KEMET
0₫
Mã kho: 1737005
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Technology | Electrolytic |
| Capacitance | 22 µF |
| Voltage | 6.3 V dc |
| Mounting Type | Surface Mount |
| Package/Case | 3216-18 |
| Equivalent Series Resistance | 90mΩ |
| Tolerance | ±20% |
| Length | 3.2mm |
| Depth | 1.6mm |
| Height | 1.6mm |
| Dimensions | 3.2 x 1.6 x 1.6mm |
| Series | T520 |
| Electrolyte Type | Solid |
| Tolerance Plus | 0.2 |
| Maximum Operating Temperature | +105°C |
| Dielectric Material Family | Tantalum |
| Minimum Operating Temperature | -55°C |
| Dissipation Factor | 0.08 |
| Terminal Type | Solder |
| Polarised | Polar |
| Tolerance Minus | -0.2 |
| Leakage Current | 13.9 μA |
