IP67 Black Cap Tactile Switch, Single Pole Single Throw (SPST) 50 mA 1.6mm Through Hole [1571407-2]; 161-5795
0₫
Mã kho: 1615795
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Contact Configuration | Single Pole Single Throw (SPST) |
| Terminal Type | Solder |
| Switch Operation | Momentary |
| Actuator Length | 1.6mm |
| Actuator Colour | Black |
| Actuator Type | Cap |
| Length | 6.3mm |
| Width | 6.4mm |
| Dimensions | 6.3 x 6.4mm |
| Illuminated | Yes |
| Mounting Type | Through Hole |
| Contact Current Rating | 50 mA |
| IP Rating | IP67 |
| Operating Force | 2.6 N |
| Contact Material | Brass, Stainless Steel |
| Minimum Operating Temperature | -35°C |
| Operating Temperature Range | -35 → +85°C |
| Maximum Operating Temperature | +85°C |
| Voltage Rating | 24V dc |
| Mechanical Life | 1000000 (Electrical)Cycles |
