Lever Tactile Switch, Single Pole Single Throw (SPST) 100 mA @ 14 V dc Through Hole [ESE20C343]; 756-1388
by Panasonic
0₫
Mã kho: 7561388
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Contact Configuration | Single Pole Single Throw (SPST) |
| Terminal Type | Solder |
| Switch Operation | Momentary |
| Actuator Type | Lever |
| Length | 8.9mm |
| Width | 5.7mm |
| Dimensions | 8.9 x 5.7mm |
| Mounting Type | Through Hole |
| Contact Current Rating | 100 mA @ 14 V dc |
| Operating Temperature Range | -30 → +80°C |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -30°C |
