IP40 Red Button Tactile Switch, Single Pole Single Throw (SPST) 50 mA 2.4mm Through Hole [PTS645SJK73-2 LFS]; 135-9191
by C & K
0₫
Mã kho: 1359191
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Contact Configuration | Single Pole Single Throw (SPST) |
| Terminal Type | PC Pin |
| Switch Operation | Momentary |
| Actuator Length | 2.4mm |
| Actuator Colour | Red |
| Actuator Type | Button |
| Length | 6mm |
| Width | 6mm |
| Dimensions | 6 x 6mm |
| Mounting Type | Through Hole |
| Contact Current Rating | 50 mA |
| IP Rating | IP40 |
| Operating Force | 260 gf |
| Contact Material | Silver Plated |
| Maximum Operating Temperature | +60°C |
| Voltage Rating | 12V dc |
| Minimum Operating Temperature | -20°C |
| Operating Temperature Range | -20 → +60°C |
