THÔNG SỐ KỸ THUẬT | |
---|---|
Number of Cores | 3 |
Cross Sectional Area | 1.5 mm² |
Outer Diameter | 10.9mm |
Minimum Operating Temperature | -15°C |
Maximum Operating Temperature | +70°C |
Voltage Rating | 300/500 V |
Core Strands | 30/0.25 mm |
Sheath Material | Polyvinyl Chloride PVC |
Sheath Colour | Transparent |
Armoured | Yes |
Earth Cable | Yes |
Standards Met | BS EN 50525 |
Screened/Unscreened | Screened |
Cable Shape | Multicore |
Screen Type | Galvanised Steel |
Length | 50m |
Bedding Material | PVC |
Conductor Material | Annealed Copper |
Insulation Material | PVC |
Minimum Bend Radius | 6 x Diameter |
Shielding | Galvanised Steel Wire Braid |
