Belden Belden SY 2 Core SY Control Cable 1.5 mm², 50m, Screened [SYSD02.0050]; 379-334
by Belden
0₫
Mã kho: 379334
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Number of Cores | 2 |
Cross Sectional Area | 1.5 mm² |
Outer Diameter | 9.58mm |
Current Rating | 16 A |
Minimum Operating Temperature | -5°C |
Maximum Operating Temperature | +70°C |
Voltage Rating | 300/500 V |
Core Strands | 30/0.25 mm |
Sheath Material | Polyvinyl Chloride PVC |
Sheath Colour | Transparent |
Earth Cable | Yes |
Series | Belden SY |
Minimum Bend Radius | 10 x D |
Conductor Material | Copper |
Bedding Material | PVC |
Screen Type | Galvanised Steel |
Screened/Unscreened | Screened |
Oil Resistant | No |
Length | 50m |
Insulation Material | PVC |
Conductor Resistance | 13.3 Ω/km |
American Wire Gauge | 15 AWG |
