TRACOPOWER Switching Regulator, 8 → 35V dc Input, 6.5V dc Output, 500mA [TSR 0.5-2465]; 166-6048
by TRACOPOWER
0₫
Mã kho: 1666048
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Input Voltage | 8 → 35V dc |
| Output Voltage | 6.5V dc |
| Number of Outputs | 1 |
| Output Current | 500mA |
| Mounting Type | Through Hole |
| Package | SIP 3 |
| Minimum Temperature | -40°C |
| Maximum Temperature | +90°C |
| Efficiency | 0.95 |
| MTBF | 2000000h |
| Load Regulation | ±0.6% |
| Line Regulation | ±0.4% |
| Ripple And Noise | 30mV Pk-Pk |
| Weight | 2g |
| Length | 11.5mm |
| Series | TSR 0.5 |
| Width | 7.55mm |
| Depth | 10.2mm |
