TRACOPOWER Switching Regulator, 4.75 → 32V dc Input, 3.3V dc Output, 500mA [TSR 0.5-2433SM]; 166-6143
by TRACOPOWER
0₫
Mã kho: 1666143
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Input Voltage | 4.75 → 32V dc |
Output Voltage | 3.3V dc |
Number of Outputs | 1 |
Output Current | 500mA |
Mounting Type | Surface Mount |
Package | SIP |
Minimum Temperature | -40°C |
Maximum Temperature | +90°C |
Efficiency | 81 % @ 32 V dc, 91 % @ Vin min |
MTBF | >2000000h |
Load Regulation | 0.006 |
Line Regulation | 0.004 |
Ripple And Noise | 30mV Pk-Pk |
Special Features | Adjustable Output Voltage, Excellent Line/Load Regulation, Low Standby Current, Remote ON/OFF Input |
Length | 15.3mm |
Standards Met | EN 55022 Certified, EN 61000-4-2 Certified, EN 61000-4-3 Certified, EN 61000-4-4 Certified, EN 61000-4-6 Certified, EN 61000-4-8 Certified, IPC J-STD-020D.1, RoHS Compliant |
Series | TSR |
Power Signal Conversion Type | DC-DC |
Maximum Input Current | 5mA |
Weight | 1.7g |
Switching Frequency Range | Maximum of 330kHz |
Protection Features | Over Temperature Protection, Short Circuit Protection |
Application | General Purpose |
Depth | 9.24 (With Pin)mm |
Width | 9.6mm |
Input Power Range | 1.5W |
