THÔNG SỐ KỸ THUẬT | |
---|---|
Input Voltage | 8 → 36V dc |
Output Voltage | 5V dc |
Number of Outputs | 1 |
Output Current | 2A |
Mounting Type | PCB Mount |
Minimum Temperature | -40°C |
Maximum Temperature | +85°C |
Efficiency | 92/89% |
MTBF | 2000 (Minimum)kh |
Load Regulation | ±1.5% |
Line Regulation | ±0.8% |
Ripple And Noise | 75mV Pk-Pk |
Switching Frequency Range | 400 (Typ.)kHz |
Depth | 17.5mm |
Width | 9mm |
Maximum Input Current | 1mA |
Allowed Circuit Configurations | Parallel |
Length | 11.5mm |
Weight | 3.8 (Typ.)g |
Power Signal Conversion Type | DC-DC |
