| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Input Voltage | 18 → 36V dc |
| Output Voltage | 15V dc |
| Number of Outputs | 1 |
| Output Current | 1A |
| Mounting Type | PCB Mount |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Efficiency | 96/94% |
| MTBF | 2000 (Minimum)kh |
| Load Regulation | ±0.6% |
| Line Regulation | ±0.4% |
| Ripple And Noise | 75mV Pk-Pk |
| Weight | 3.8 (Typ.)g |
| Switching Frequency Range | 580 → 780kHz |
| Depth | 17.5mm |
| Maximum Input Current | 1mA |
| Length | 11.5mm |
| Allowed Circuit Configurations | Parallel |
| Width | 9mm |
| Power Signal Conversion Type | DC-DC |
