| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Input Voltage | 6.5 → 36V dc |
| Output Voltage | 5V dc |
| Number of Outputs | 1 |
| Output Current | 500mA |
| Mounting Type | PCB Mount |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Efficiency | 90/84% |
| MTBF | 2000 (Minimum)kh |
| Load Regulation | ±0.6 (Typ.)% |
| Line Regulation | ±0.4% |
| Ripple And Noise | 75mV Pk-Pk |
| Width | 7.2mm |
| Depth | 11mm |
| Switching Frequency Range | 550 → 850kHz |
| Weight | 1 (Typ.)g |
| Power Signal Conversion Type | DC-DC |
| Allowed Circuit Configurations | Parallel |
| Maximum Input Current | 1.5mA |
| Length | 10mm |
