Switching Voltage Regulator 2A Synch.R [MAX1644EAE+]; 190-8116
0₫
Mã kho: 1908116
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Input Voltage | 3 → 5.5V dc |
| Output Voltage | 3.3 → 3.36V dc |
| Number of Outputs | 1 |
| Output Current | 2.5A |
| Mounting Type | Surface Mount |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Efficiency | 0.95 |
| Load Regulation | 1mV |
| Width | 5.38mm |
| Maximum Input Current | 6.5µA |
| Length | 6.33mm |
| Switching Frequency Range | 350kHz |
| Protection Features | Thermal Shutdown |
| Application | CPU Daughter Card Supply, CPU I/O Supply, Desktop Bus-Termination Boards, Notebook and Subnotebook Computers, +3.3V PC Card and CardBus Applications, +5V to +3.3V/+2.5V Conversion |
| Depth | 1.78mm |
| Power Signal Conversion Type | DC-DC |
