Siemens 20 A SPNO Solid State Relay, Zero Crossing, DIN Rail, Thyristor, 600 V Maximum Load [3RF2320-1AA06]; 467-4863
by Siemens
0₫
Mã kho: 4674863
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 0.5 A |
| Range | Sirius Classic |
| Maximum Load Current | 20 A |
| Mounting Type | DIN Rail |
| Minimum Load Voltage | 48 V |
| Maximum Load Voltage | 600 V |
| Minimum Control Voltage | 15 V dc |
| Maximum Control Voltage | 24 V dc |
| Switching Type | Zero Crossing |
| Contact Configuration | SPNO |
| Terminal Type | Screw |
| Output Device | Thyristor |
| Maximum Turn On Time | 1 (+1/2 cycle) ms |
| Dimensions | 22.5 x 140.5 x 100mm |
| Load Voltage Range | 48 → 600V |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +60°C |
| Control Voltage Range | 15 → 24 V dc |
| Depth | 140.5mm |
| Operating Temperature Range | -25 → +60°C |
| Height | 100mm |
| Off State Leakage Current | 10 mA |
| Length | 22.5mm |
