![Sensata / Crydom PMP2425W 1450603](http://nguyenxuong.com/cdn/shop/products/R1450603-01_225x444.jpg?v=1594086368)
Sensata / Crydom 25 A Solid State Relay, Burst Fire Control, Phase Angle, Panel Mount, 280 V ac Maximum Load [PMP2425W]; 145-0603
0₫
Mã kho: 1450603
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Minimum Load Current | 100 mA rms |
Range | NOVA22 |
Maximum Load Current | 25 A |
Mounting Type | Panel Mount |
Series | PMP |
Minimum Load Voltage | 90 V ac |
Maximum Load Voltage | 280 V ac |
Minimum Control Voltage | 0 V dc |
Maximum Control Voltage | 5 V dc, 10 V dc |
Switching Type | Burst Fire Control, Phase Angle |
Terminal Type | Screw |
Maximum Turn On Time | 20 cycles |
Dimensions | 22.5 x 53.1 x 91.9mm |
Number of Poles | 1 |
Depth | 53.1mm |
Standards Met | CE, CSA C22.2 No. 14, CULus Recognised E116949, EMC Compliant, IEC, IEC 60068-2-27, IEC 60068-2-6, UL, UL 94 V-0 |
Load Voltage Range | 90 → 280V ac |
Control Voltage Range | 0 → 10 V dc, 0 → 5 V dc |
Operating Temperature Range | -25 → +70°C |
Length | 22.5mm |
Off State Leakage Current | 4 mArms |
Maximum Operating Temperature | +70°C |
Special Features | LED Multifunction Status Indicator |
Relay Type | Control Relay |
Minimum Operating Temperature | -25°C |
Height | 91.9mm |
Capacitance | 8pF |
