Sensata / Crydom 18 Arms Solid State Relay, Zero Crossing, Panel Mount, SCR, 280 Vrms Maximum Load [EZ240D18]; 145-0595
0₫
Mã kho: 1450595
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 150 mA rms |
| Maximum Load Current | 18 A rms |
| Series | EZ |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 24 Vrms |
| Maximum Load Voltage | 280 Vrms |
| Minimum Control Voltage | 3 V dc |
| Maximum Control Voltage | 15 V dc |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Output Device | SCR |
| Maximum Turn On Time | 1/2 cycles |
| Dimensions | 43.9 x 38.1 x 13.9mm |
| Maximum Operating Temperature | +80°C |
| Operating Temperature Range | -40 → +80°C |
| Capacitance | 8pF |
| Control Voltage Range | 3 → 15 V dc |
| Minimum Operating Temperature | -40°C |
| Off State Leakage Current | 0.1 mArms |
| Length | 43.9mm |
| Load Voltage Range | 24 → 280Vrms |
| Height | 13.9mm |
| Number of Poles | 1 |
| Depth | 38.1mm |
| Relay Type | Solid State Relay |
| Standards Met | CE, CSA LR 81689, CULus Recognised E116950, EN 60950, EN 60950-1, IEC 62314, UL, VDE Approved 10139 UG |
| Special Features | AC or DC Control, Compact Design for Low-Profile Applications |
