Sensata / Crydom 7 A SP-NC Solid State Relay, DC, Surface Mount, Transistor, 60 V dc Maximum Load [DC60S7-B]; 736-0882
0₫
Mã kho: 7360882
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 20 mA |
| Maximum Load Current | 0.291666666666667 |
| Mounting Type | Surface Mount |
| Minimum Load Voltage | 3 V dc |
| Maximum Load Voltage | 60 V dc |
| Minimum Control Voltage | 3.5 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | DC |
| Contact Configuration | SP-NC |
| Terminal Type | Screw |
| Output Device | Transistor |
| Maximum Turn On Time | 0.1 ms |
| Dimensions | 45.7 x 19.8 x 58.4mm |
| Control Voltage Range | 3.5 → 32 V dc |
| Maximum Operating Temperature | +80°C |
| Depth | 19.8mm |
| Operating Temperature Range | -30 → +80°C |
| Load Voltage Range | 3 → 60V dc |
| Off State Leakage Current | 0.1 mA |
| Length | 45.7mm |
| Minimum Operating Temperature | -30°C |
| Height | 58.4mm |
