Sensata / Crydom 90 A SPST Solid State Relay, Instantaneous, Panel Mount, SCR, 280 V rms Maximum Load [D2490-10]; 736-0876
0₫
Mã kho: 7360876
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 40 mA rms |
| Maximum Load Current | 90 A |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 24 V rms |
| Maximum Load Voltage | 280 V rms |
| Minimum Control Voltage | 3 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Instantaneous |
| Contact Configuration | SPST |
| Terminal Type | Screw |
| Output Device | SCR |
| Maximum Turn On Time | 1/2 cycle |
| Dimensions | 45.7 x 19.8 x 58.4mm |
| Off State Leakage Current | 10 mA rms |
| Length | 45.7mm |
| Height | 58.4mm |
| Operating Temperature Range | -40 → +80°C |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +80°C |
| Depth | 19.8mm |
| Load Voltage Range | 24 → 280Vrms |
| Control Voltage Range | 3 → 32 V dc |
