Sensata / Crydom 25 A Solid State Relay, Zero Cross, Panel Mount, SCR, 660 V ac Maximum Load [CWU4825P]; 776-1787
0₫
Mã kho: 7761787
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 0.15 A |
| Maximum Load Current | 25 A |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 48 V ac |
| Maximum Load Voltage | 660 V ac |
| Minimum Control Voltage | 20 V ac/dc |
| Maximum Control Voltage | 48 V dc, 280 V ac |
| Switching Type | Zero Cross |
| Terminal Type | Screw |
| Output Device | SCR |
| Maximum Turn On Time | 17 ms |
| Dimensions | 45.7 x 33 x 58.4mm |
| Length | 45.7mm |
| Off State Leakage Current | 1 mA |
| Height | 58.4mm |
| Control Voltage Range | 20 → 280 V ac, 20 → 48 V dc |
| Depth | 33mm |
| Load Voltage Range | 48 → 660V ac |
| Operating Temperature Range | -40 → +80°C |
