Sensata / Crydom 30 A SPST Solid State Relay, Instantaneous, DIN Rail, SCR, 280 V rms Maximum Load [CKRA2430-10]; 736-0829
0₫
Mã kho: 7360829
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Minimum Load Current | 0.15 A rms |
Maximum Load Current | 30 A |
Mounting Type | DIN Rail |
Minimum Load Voltage | 24 V rms |
Maximum Load Voltage | 280 V rms |
Minimum Control Voltage | 90 V ac |
Maximum Control Voltage | 280 V ac |
Switching Type | Instantaneous |
Contact Configuration | SPST |
Terminal Type | Screw |
Output Device | SCR |
Maximum Turn On Time | 10 ms |
Dimensions | 22.5 x 81.3 x 81.9mm |
Maximum Operating Temperature | +80°C |
Control Voltage Range | 90 → 280 V ac |
Operating Temperature Range | -40 → +80°C |
Depth | 81.3mm |
Load Voltage Range | 24 → 280Vrms |
Minimum Operating Temperature | -40°C |
Height | 81.9mm |
Off State Leakage Current | 10 mA rms |
Length | 22.5mm |
