![Panasonic APT1222 6996487](http://nguyenxuong.com/cdn/shop/products/W6996471-01_bbea2883-2899-4641-870e-22d68faeea91_416x444.jpg?v=1594410403)
Panasonic 3.5 mA SPNO Solid State Relay, Random, PCB Mount, Triac, 600 V Maximum Load [APT1222]; 699-6487
by Panasonic
0₫
Mã kho: 6996487
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Minimum Load Current | 0.3 mA |
Maximum Load Current | 3.5 mA |
Mounting Type | PCB Mount |
Maximum Load Voltage | 600 V |
Minimum Control Voltage | 1.21 V |
Maximum Control Voltage | 1.3 V |
Switching Type | Random |
Contact Configuration | SPNO |
Terminal Type | Through Hole |
Output Device | Triac |
Package Style | DIP6 |
Maximum Turn On Time | 100 μs |
Dimensions | 8.8 x 6.4 x 3.9mm |
Length | 8.8mm |
Off State Leakage Current | 1 μA |
Height | 3.9mm |
Minimum Operating Temperature | -40°C |
Maximum Operating Temperature | +100°C |
Control Voltage Range | 1.21 → 1.3 V |
Depth | 6.4mm |
Operating Temperature Range | -40 → +100°C |
