i-Autoc 60 A Solid State Relay, Zero Cross, Panel Mount, SCR, Triac, 530 V ac Maximum Load [KSI480D60-L]; 164-0572
by i-Autoc
0₫
Mã kho: 1640572
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Maximum Load Current | 60 A |
Mounting Type | Panel Mount |
Series | KSI |
Minimum Load Voltage | 48 V ac |
Maximum Load Voltage | 530 V ac |
Minimum Control Voltage | 4 V dc |
Maximum Control Voltage | 32 V dc |
Switching Type | Zero Cross |
Terminal Type | Screw |
Output Device | SCR, TRIAC |
Maximum Turn On Time | 10 ms |
Dimensions | 58.4 x 45.7 x 20.5mm |
Minimum Operating Temperature | -30°C |
Control Voltage Range | 4 → 32 V dc |
Special Features | Build-In MOV/TVS Option, DC Control, Dielectric Strength, LED Indicator, TRIAC or SCR Output |
Operating Temperature Range | -30 → +80°C |
Length | 58.4mm |
Off State Leakage Current | 5 mA |
Maximum Operating Temperature | +80°C |
Relay Type | Single Phase |
Height | 20.5mm |
Depth | 45.7mm |
Standards Met | CCCs, CE, CULus, TUV |
Load Voltage Range | 48 → 530V ac |
