Kudom 60 A Solid State Relay, Zero Crossing, Panel Mount, SCR, 530 V ac Maximum Load [KSI480D60-L(068)]; 903-2930
by i-Autoc
0₫
Mã kho: 9032930
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Maximum Load Current | 60 A |
Mounting Type | Panel Mount |
Minimum Load Voltage | 48 V ac |
Maximum Load Voltage | 530 V ac |
Minimum Control Voltage | 4 V dc |
Maximum Control Voltage | 32 V dc |
Switching Type | Zero Crossing |
Terminal Type | Screw |
Output Device | SCR |
Maximum Turn On Time | 1 (1/2 AC Cycle) ms |
Dimensions | 58.6 x 45.7 x 26.5mm |
Depth | 45.7mm |
Control Voltage Range | 4 → 32 V dc |
Load Voltage Range | 48 → 530V ac |
Standards Met | CE, TUV, UL |
Relay Type | Industrial Single Phase Relay |
Length | 58.6mm |
Operating Temperature Range | -30 → +80°C |
Height | 26.5mm |
Off State Leakage Current | 3 mA |
Special Features | DBC Substrate for Superior Thermal Performance, Internal MOV, Internal RC, LED Indication, TVS Protection Circuit as Option |
