Kudom 60 A Solid State Relay, Zero Crossing, Panel Mount, SCR, Triac, 280 V ac Maximum Load [KSI240D60-L]; 903-2968
by i-Autoc
0₫
Mã kho: 9032968
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Load Current | 60 A |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 48 V ac |
| Maximum Load Voltage | 280 V ac |
| Minimum Control Voltage | 4 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Output Device | SCR, Triac |
| Maximum Turn On Time | 1 (1/2 AC Cycle) ms |
| Dimensions | 58.6 x 45.7 x 26.5mm |
| Depth | 45.7mm |
| Load Voltage Range | 48 → 280V ac |
| Control Voltage Range | 4 → 32 V dc |
| Relay Type | Industrial Single Phase Relay |
| Special Features | Internal MOV, Internal RC, LED Indication, Superior Thermal Performance, TVS Protection Circuit as Option |
| Standards Met | CE, TUV, UL |
| Operating Temperature Range | -30 → +80°C |
| Height | 26.5mm |
| Off State Leakage Current | 5 mA |
| Length | 58.6mm |
