Finder 6 A SPNO Solid State Relay, DC, DIN Rail, 24 V dc Maximum Load [39.20.7.012.9024]; 776-1443
by Finder
0₫
Mã kho: 7761443
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 1 mA |
| Maximum Load Current | 0.25 |
| Mounting Type | DIN Rail |
| Series | Series 39 |
| Minimum Load Voltage | 1.5 V dc |
| Maximum Load Voltage | 24 V dc |
| Minimum Control Voltage | 9.6 V dc |
| Maximum Control Voltage | 13.2 V dc |
| Switching Type | DC |
| Contact Configuration | SPNO |
| Terminal Type | Screw |
| Package Style | Interface Module |
| Maximum Turn On Time | 0.6 ms |
| Dimensions | 85 x 6.2 x 87mm |
| Length | 6.2mm |
| Off State Leakage Current | 0.001 mA |
| Height | 87mm |
| Control Voltage Range | 12 V dc |
| Minimum Operating Temperature | -20°C |
| Operating Temperature Range | -20 → +55°C |
| Load Voltage Range | 1.5 → 24V dc |
| Depth | 90.7mm |
| Maximum Operating Temperature | +55°C |
