Celduc 50 A Solid State Relay, Zero Crossing, Chassis Mount, Thyristor, 600 V ac Maximum Load [SVT965760]; 307-3304
by Celduc
0₫
Mã kho: 3073304
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Minimum Load Current | 5 mA |
Maximum Load Current | 50 A |
Mounting Type | Panel Mount |
Minimum Load Voltage | 24 V ac |
Maximum Load Voltage | 600 V ac |
Minimum Control Voltage | 10 V ac/dc |
Maximum Control Voltage | 30 V ac/dc |
Switching Type | Zero Crossing |
Output Device | Thyristor |
Maximum Turn On Time | 30 ms |
Dimensions | 100 x 76 x 56.5mm |
Off State Leakage Current | 1 mA |
Height | 56.5mm |
Maximum Operating Temperature | +100°C |
Minimum Operating Temperature | -40°C |
Length | 100mm |
Operating Temperature Range | -40 → +100°C |
Load Voltage Range | 24 → 600V ac |
Depth | 76mm |
Control Voltage Range | 10 → 30 V ac/dc |
