Celduc 25 A Solid State Relay, Random, PCB Mount, Thyristor, 600 V ac Maximum Load [SKL20241]; 917-4765
by Celduc
0₫
Mã kho: 9174765
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Minimum Load Current | 5 mA |
| Maximum Load Current | 25 A |
| Mounting Type | PCB Mount |
| Minimum Load Voltage | 24 V ac |
| Maximum Load Voltage | 600 V ac |
| Minimum Control Voltage | 8 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Random |
| Terminal Type | PCB Pin |
| Output Device | Thyristor |
| Package Style | SIP4 |
| Maximum Turn On Time | 0.1 ms |
| Dimensions | 43.4 x 6.3 x 24.5mm |
| Relay Type | AC |
| Control Voltage Range | 8 → 32 V dc |
| Load Voltage Range | 24 → 600V ac |
| Standards Met | CULus Recognized |
| Depth | 6.3mm |
| Special Features | Range for Printed Circuit Board for Mounting on an External Heatsink, Thyristor DCB Technology, Zero-Cross AC Output |
| Height | 24.5mm |
| Off State Leakage Current | 1 mA |
| Operating Temperature Range | -40 → +80°C |
| Length | 43.4mm |
