Celduc 50 A Solid State Relay, Zero Cross, PCB Mount, Thyristor, 690 V ac Maximum Load [SKL10560]; 917-4756
by Celduc
0₫
Mã kho: 9174756
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Minimum Load Current | 5 mA |
Maximum Load Current | 50 A |
Mounting Type | PCB Mount |
Minimum Load Voltage | 24 V ac |
Maximum Load Voltage | 690 V ac |
Minimum Control Voltage | 4 V dc |
Maximum Control Voltage | 14 V dc |
Switching Type | Zero Cross |
Terminal Type | PCB Pin |
Output Device | Thyristor |
Package Style | SIP4 |
Maximum Turn On Time | 10 ms |
Dimensions | 43.4 x 6.3 x 24.5mm |
Standards Met | CULus Recognized |
Relay Type | AC |
Special Features | Range for Printed Circuit Board for Mounting on an External Heatsink, Thyristor DCB Technology, Zero-Cross AC Output |
Depth | 6.3mm |
Load Voltage Range | 24 → 690V ac |
Control Voltage Range | 4 → 14 V dc |
Length | 43.4mm |
Height | 24.5mm |
Operating Temperature Range | -40 → +80°C |
Off State Leakage Current | 1 mA |
