Celduc 25 A Solid State Relay, Random, PCB Mount, Thyristor, 690 V ac Maximum Load [SKL10260]; 917-4747
by Celduc
0₫
Mã kho: 9174747
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Minimum Load Current | 5 mA |
Maximum Load Current | 25 A |
Mounting Type | PCB Mount |
Minimum Load Voltage | 24 V ac |
Maximum Load Voltage | 690 V ac |
Minimum Control Voltage | 4 V dc |
Maximum Control Voltage | 14 V dc |
Switching Type | Random |
Terminal Type | PCB Pin |
Output Device | Thyristor |
Package Style | SIP4 |
Maximum Turn On Time | 10 ms |
Dimensions | 43.4 x 6.3 x 24.5mm |
Height | 24.5mm |
Off State Leakage Current | 1 mA |
Length | 43.4mm |
Operating Temperature Range | -40 → +80°C |
Standards Met | CULus Recognized |
Relay Type | AC |
Special Features | Random AC Output, Range for Printed Circuit Board for Mounting on an External Heatsink, Thyristor DCB Technology |
Depth | 6.3mm |
Load Voltage Range | 24 → 690V ac |
Control Voltage Range | 4 → 14 V dc |
